Laizap Opto-electros, a professional manufacturer of Red 12 Lines Laser Level meters, has won a good reputation in the market with advanced technology and rigorous quality control. Knowing that precise measurement is crucial to the success or failure of a project, we promise that every laser level undergoes strict quality control and performance testing to ensure excellent performance under complex working conditions. I am willing to work hand in hand with you to lay the foundation for success in every measurement.
Laizap Opto-electros is not only a leader in the manufacturing field, but also a reliable partner for you. We are eager to walk shoulder to shoulder with you, explore new fields of optoelectronic measurement technology together, and share our profound accumulation in the design, manufacturing, and application of laser level instruments. We firmly believe that cooperation and innovation can work together to provide more efficient and accurate measurement solutions for global customers. Let's work together to open a new chapter in optoelectronic measurement and turn every challenge into a successful milestone.
Light Source-Red |
630nm - 650nm |
LD power |
30mw |
Accuracy |
± 3mm / 10m |
Laser class |
Level 2 (output power<1mW) Class 2 |
Laser beam |
one 360° horizontal line + two 360° vertical lines |
Self-leveling range |
4° ± 1° |
Working distance |
100ft/30m, 200ft/60m with detector (red beam) |
Operating time |
8H/ three gears ;12H/ two gears ;24H/ one gear; |
Power source |
7.4V-2600mah lithium battery |
USB charging |
Yes |
Mount size |
1/4"-20 and 5/8"-20 mounting thread |
IP rating |
IP54 |
Function |
Self-leveling mode, manual mode, and pulse mode. |
Working temperature |
-10℃ ~ 50℃ |
Storage temperature |
-20 ~ 70℃ |
Packing - Carry bag |
Kit included: 1. LP360 laser level 2. multiple bracket 3. Type-C Power cable 4. 2X battery 5. instruction book 6. bag 7. color box |
Packing - Plastic case |
Kit included: 1. LP360 laser level 2. multiple bracket 3. back clip 4. target plate 5. red glasses 6. 2X battery 7. Type-C Power cable 8. Power Adaptor 9. instruction book 10. plastic case 11. color sleeve |
